Voumard Type 5A Internal Grinding Machine

Product Description

Make - Voumard (Switzerland)

Model - 5A

Grinding Diameter - 5 mm to 200 mm

Center Height - 180 mm

Max. Swing Diameter of Job - 360 mm

Grinding Depth - 250 mm

Maximum Table Stroke - 600 mm

Spindle Speeds - 3,600 rpm to 40,000 rpm

Work-Head Speeds - 125 rpm to 1,000 rpm

Work-Head Swivel - 0 Degree to 90 Degree

- Equipped with Face Grinding Attachment.

- Equipped with Hydraulic Wheel-Dresser.

- Auto Cycle Working.

- Operating Manual & Electrical Drawings available.

- Machine is in excellent working condition.

Video link - https://youtu.be/uGv4jscQVwM
