MAS Radial Drilling Machine

Product Description

MAS Radial Drilling Machine

MAS (Czech Republic) make Radial Drilling Machine in excellent working condition. The model of the machine is VR4 and the Drilling Capacity is 50 mm.

The technical details are as follows -

• Make - MAS (Czech Republic)
• Model - VR4
• Drilling Capacity - 50 mm
• Spindle Diameter - 75 mm
• Arm Length - 1470 mm
• Spindle Speeds - 45 rpm to 2000 rpm
• Spindle Taper - MT4
• Spindle Feed Travel - 310 mm
• Spindle Feed Rate of Travel - 0.025 mm/rev to 1.58 mm/rev
• Vertical Travel of Arm - 675 mm
• Cube Table Size - 555 mm x 555 mm
• Clamping Type - Manual
• Machine is in excellent working condition.

Video Link - https://youtu.be/5vpps9tnTA4
