Giustina Vertical Rotary Surface Grinder

Giustina Vertical Rotary Surface Grinder

8000 INR/Piece

Product Details:

X

Price And Quantity

  • 1 Piece
  • 8000 INR/Piece

Product Description

Giustina (Italy) make Vertical Rotary Surface Grinding Machine in excellent working condition. The Table Diameter of the Machine is 1000 mm and the Segmented Wheel Cup Diameter is 510 mm. The technical details are as follows -


Make - Giustina (Italy)

Magnetic Table Diameter - 1000 mm

Cup Wheel Diameter - 510 mm

Table Rotation Speeds - 6 rpm to 36 rpm

Wheel Type - Segmented ; 10 pcs.

Grinding Wheel Spindle Motor - 30 HP

Max. Height of Job - 300 mm

Magnet Type - Electro-Magnet

Weight of the Machine - 6 tons (approximately)

- Motorised Rapid Vertical Travel of Wheel-Head.

- Hydraulic Rapid Forward & Backward Movement of Table.

- Feature of Automatic Depth Adjustment "Auto-Cut".

- Equipped with a Grinding Wheel Dresser.

- Complete with Coolant Pump & Coolant Tank.

- Machine is in excellent working condition.


Video link - https://youtu.be/-2jjsEmKMGA
