Arno Nomo Bed Milling Machine

Arno Nomo Bed Milling Machine

22700 INR/Piece

Product Details:

X

Price And Quantity

  • 1 Piece
  • 22700 INR/Piece

Product Description

Arno-Nomo (Italy) make Heavy-Duty Bed Milling Machine in excellent working condition.The Table Size of the machine is 2200 mm x 700 mm. The technical details are as follows -


Make - Arno-Nomo (Italy)

Table Size - 2200 mm x 700 mm

XYZ Travel - 2000 mm x 1000 mm x 950 mm

Horizontal Spindle Taper - ISO 50

Horizontal Spindle Speeds - 28 rpm to 1500 rpm

Vertical Spindle Taper - ISO 50

Feed Rate of Travel - 10 mm/min to 913 mm/min

Over-Arm Travel (Cross Travel) of Vertical Milling Head - 900 mm

Horizontal Spindle Motor - 11 kW

Vertical Spindle Motor - 7.5 kW

- Equipped with a 3-Axis DRO.

- Vertical Milling Head is Double-Swivel type.

- Complete with lots of Cutters, Tool Holders etc.

- Machine is in excellent working condition.


Video link - https://youtu.be/MkqKJhEuo1w
