                Schaublin CNC Turn Mill Center

                Schaublin CNC Turn Mill Center
                Schaublin CNC Turn Mill Center
                Product Code : CNCTMC Schaublin
                Brand Name : Schaublin
                Product Description

                CNC Turn-Mill Centre

                • Make - Schaublin (Switzerland)
                • Model - 110-CNC-R
                • No. of Axes - 4
                • No. of Turrets - 2
                • Max. Turning Diameter - 115 mm
                • Max. Turning Length - 300 mm
                • CNC Control - Fanuc O-TC
                • Transversal Travel - 220 mm
                • Longitudinal Travel - 295 mm
                • Resolution of Z Axis - 0.0001 mm
                • Resolution of X Axis - 0.00005 mm
                • - Machine with Hydrobar type bar feeder.
                • Main Turret -
                • No. of Tool Position - 8
                • No. of motorized Positions - 8 front / 4 radial
                • Diameter of Bore in tool position - 35 mm
                • Lower Turret with Fixed Tools -
                • Number of Tool Positions - 6
                • Bore Diameter of Tool Positions - 35 mm
                • Fixed Tool Section - 12 mm x 12 mm
